106 Installing System Components
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
NOTE: The procedure for removing each individual fan module is the same.
1 Turn off the system, including any attached peripherals, and disconnect
the system from its electrical outlet.
2 Open the system. See "Opening the System" on page 80.
3 Remove the system board shroud. See "Removing the System Board
Shroud" on page 98.
4 Disconnect the fan’s power cable from the system board. See Figure 3-15.
5 Remove the faulty fan by grasping the fan and sliding the fan from the fan
assembly. See Figure 3-15.
Figure 3-15. Removing and Installing a Fan
1 fan 2 power cable
1
2
