Installing System Components 127
3 Open the system. See "Opening the System" on page 80.
4 Disconnect the control panel cable at back of the control panel board. See
Figure 3-24.
CAUTION: Do not pull on the cable to unseat the connector. Doing so can damage
the cable.
a
Press the metal tabs on the ends of the cable connector.
b Gently work the connector out of the socket.
5 Disconnect the display module cable from the control panel board. See
Figure 3-24.
6 Remove the two screws that secure the control panel board to the system
chassis and remove the board.
7 To remove the display module, use a knife or a small flat-blade screwdriver,
insert the blade beneath the front panel of the display and slide the blade
across the bottom to lift the panel outward. See Figure 3-24.
8 Bend the panel upward to allow access to the mounting screws.
9 Remove the two screws that secure the display module to the system
chassis.
10 Remove the display module from the chassis cutout.
