Installing System Components 101
Figure 3-13. Removing and Installing an iDRAC6 Express Card
7 Close the system. See "Closing the System" on page 81.
8 Reconnect the system and peripherals to their power sources, and turn
them on.
Removing an iDRAC6 Express Card (Optional)
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1 Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2 Open the system. See "Opening the System" on page 80.
1 iDRAC6 Express card 2 notch
3 clip 4 plastic standoff tab
1 2
3 4
