Navigating System Diagnostics
Table 3-1 lists the basic keys used to view or change information in the screens and to exit the program. The keys used
to navigate screens in the appliance differ, depending on the version of the operating system installed on your console
redirection client system.
Because of ANSI limitations, not all keys can be used with console redirection. Table 3-2 shows keystroke combinations
used for the version of Windows on your client system.
Table 3-1. Diagnostics Navigation Keys
Keys Action
or
Moves to the next field.
Up arrow Moves to the previous field.
Space
bar
Selects or deselects options on menus. Selected options display an asterisk.
Starts a test or displays submenus.
Cancels the current operation or returns to the previous menu. On the main menu, exits the System
Diagnostics program and reboots the system.
For most of the options, any changes you make are recorded but do not take effect until you reboot the
system. For a few options (as noted in the help area), the changes take effect immediately.
Table 3-2. Console Redirection Keys
Normal Keys (As They Appear
on the Keyboard)
Keys Used for Windows 2000 Prior
to Service Pack 2
Keys Used for All Other Windows
Operating Systems
Home
End
Insert <+> <+>
Delete <-> <->
Page Up < Esc>
Page Down
F1 <1>
F2 <2>
F3 <3>
F4 <4>
F5 <5> <5>
F6 <6> <6>
F7 <7> <7>
F8 <8> <8>
F9 <9> <9>
F10 <0> <0>
F11
F12 <@> <@>
Up arrow Up arrow
Right arrow Right arrow
Left arrow Left arrow
Down arrow Down arrow
