Each hard drive has two LEDs. The LEDs are most visible when the bezel is attached to the front of the system. The LEDs
provide the following information for each hard drive:
When the LED on the left side is green, the hard drive is installed in the drive bay and working. When this LED is
amber, the hard drive is installed in the bay, but it is not working properly.
When the LED on the right side flashes amber, the hard drive is active.
System Messages
System messages alert you to a possible operating system problem or a conflict between the software and hardware.
To view system messages, perform the following steps:
1. Connect a client system to the appliance and enter the BIOS Setup utility.
See your User's Guide for information about entering the BIOS Setup utility.
2. Select Advanced CMOS Setup.
3. Select View DMI Event and press .
Table 2-1 lists the system error messages and the probable cause for each message.
Table 2-1. System Messages
Message Cause Corrective Action
HDD
Controller
Failure BIOS cannot
communicate with the
hard drive controller.
Check the connections to the hard drive.
CMOS
Battery
Low The battery on the
system is low or faulty.
Replace the system battery. See " Replacing the System Battery " in "Installing
System Board Options." If the problem persists, replace the system board. See
" Getting Help ," for information about obtaining technical assistance.
CMOS
Checksum
Bad The checksum value
(CMOS RAM settings)
differs from the current
value.
In the BIOS Setup utility, select to autoload the optimal setting. See "Using the
BIOS Setup Utility," in your User's Guide for information about changing this
setting.
CMOS Time
and Date
Not Set The BIOS does not have
date and time values.
Use the BIOS Setup utility to set the time and date. See "Using the BIOS Setup
Utility," in your User's Guide for information about changing this setting.
Pri Master
HDD error Primary hard drive is not
responding.
Replace the primary hard drive. See " Installing Hard Drives ." If the problem still
persists, see " Getting Help ," for information about obtaining technical
assistance.
Sec Master
HDD error Secondary hard drive is
not responding.
Replace the secondary drive. See " Installing Hard Drives ." If the problem still
persists, see " Getting Help ," for information about obtaining technical
assistance.
Cache
Memory
Error Cache memory is
defective.
Disable the cache in the BIOS Setup utility. See "Using the BIOS Setup Utility,"
in your User's Guide for information about changing this setting.
System Beep Codes
When an error that cannot be reported through a console redirection screen occurs during a boot routine, the system
might emit a series of beeps that identify the problem. For example, five beeps indicate a problem with the processor.
This information is valuable to the Dell technical support representative if you must call for technical assistance.
When a beep code is emitted, record it, and then look it up in Table 2-2 . If you are unable to resolve the problem by
looking up the meaning of the beep code, use the System Diagnostics to identify a more serious cause. If you are still
unable to resolve the problem, see " Getting Help ," for information about obtaining technical assistance.
