System Board Labels
Table 2 lists the connectors and sockets located on the system board.
Table 2. System Board Connectors and Sockets
Disabling a Forgotten Password
The computer's software security features include a supervisor password and a user password, which are discussed in detail in "Using the System Setup
Program" of the User's Guide. A password jumper on the system board enables these password features or disables them and clears any password(s)
currently in use.
To disable a forgotten supervisor password or user password, perform the following steps.
1. Turn off the system, including any attached peripherals, and disconnect the power cord from its power source.
2. Remove the system cover .
3. See Figure 1 for the location of the password jumper (labeled PASSWORD) on the system board.
4. Remove the jumper plug from the PASSWORD jumper.
5. Replace the system cover and then reconnect the computer to an electrical outlet and turn it on.
The existing passwords are not disabled (erased) until the system boots with the PASSWORD jumper plug removed. However, before you assign a new
system and/or user password, you must install the jumper plug.
6. Repeat step 1.
7. Install the jumper plug on the PASSWORD jumper.
8. Replace the system cover and then reconnect the computer and peripherals to their electrical outlets and turn them on.
9. Assign a new system and/or user password.
To assign a new system and/or user password, see "
Using the System Setup Program ".
Back to Contents Page
Connector or Socket Description
BATTERY Battery connector
COM1 Serial port connector
CPU Microprocessor ZIF socket
DIMM_n Memory module sockets
FDD Diskette drive cable connector
FRONT PANEL System front panel connector
LAN1 RJ45 Ethernet NIC connector
J12 System jumpers
KY Keyboard connector
LPT Parallel port connector
MS Mouse connector
POWER Power connector
PRIMARY IDE Primary IDE connector
SECONDARY IDE Secondary IDE connector
SLOT_n Ultra3 SCSI host adapter connector
SYS_FAN2 Fan connector
USB USB connector
VGA Video connector
CAUTION: Read the safety instructions in your System Information document.
NOTE: If you assign a new system and/or user password with the jumper plug still removed, the system disables the new password(s) the next
time it boots.
