l System diagnostics are available on the utility partition, which checks for hardware problems (if the system can boot). The system diagnostics can be
downloaded to diskettes from the Dell OpenManage Server Assistant CD.
l Embedded server management hardware, which monitors temperatures and voltages throughout the system and notifies you if the system overheats, if
a system cooling fan malfunctions, if a processor overheats, or if a power supply or VRM fails.
The system chassis simplifies removing and replacing system components. You can replace the microprocessor or DIMMs without removing the system board.
Technical Specifications
Microprocessor
Microprocessor type Intel Pentium III microprocessor with a minimum of 1 GHz, an external bus speed of 133 MHz, and a 256 KB
level 2 cache
OR
Intel Celeron microprocessor at 800 MHz with an external bus speed of 100 MHz and a 128 KB level 2 cache
Front-side bus speed Pentium III: 133 MHz
Celeron: 100 MHz
Internal cache Pentium III: 256 KB Level 2 cache
Celeron: 128 KB Level 2 cache
Expansion Bus
Bus type PCI
Expansion slots Two 64-bit, 33/66-MHz slots
Three 32-bit, 33-MHz slots
Memory
Architecture 72-bit ECC PC-133 SDRAM
Memory module sockets four
Memory module capacities 64, 128, 256, or 512 MB
Minimum RAM 64 MB
Maximum RAM 2 GB
Drives
Diskette drive 3.5-inch, 1.44-MB diskette drive
Tape drive optional internal tape drive
IDE devices three 1-inch, internal, IDE hard drive bays
CD drive one IDE CD drive
Ports and Connectors
Externally accessible:
Serial (DTE) one 9-pin connector; 16550-compatible
Parallel one 25-pin connector (bidirectional)
Video one 15-pin connector
PS/2-style keyboard 6-pin mini-DIN connector
PS/2-compatible
mouse 6-pin mini-DIN connector
USB two USB-compliant 4-pin connectors
NIC RJ45 connector for integrated NIC
Video
Video type ATI Rage XL video controller; VGA connector
Video memory 4 MB
Power
DC power supply:
Wattage one 250-W or 330-W power supply
Voltage 90–240 V, 47/63 Hz or 90–265 V, 47/63 Hz
System battery CR2032 3.0-V lithium coin cell
Physical
Height 43.7 cm (17.2 inches)
Width 20.3 cm (8 inches)
Depth 44.5 cm (17.5 inches)
Weight 15.0 kg (33 lb), maximum configuration
Environmental
Temperature:
