94 Installing System Components
11 Place the system upright on a flat surface.
12 Reattach any peripherals and connect the system to an electrical outlet.
13 Turn on the system and attached peripherals.
14 Test the drive by running system diagnostics (optional). See "Running the
System Diagnostics" on page 147.
Power Supply
Removing a Power Supply
1 Turn off the system and all attached peripherals.
2 Disconnect the power cable from the power supply.
3 Open the system. See "Opening the System" on page 79.
4 Disconnect all cables from the power supply to the system board,
hard drives and optical drive.
5 Loosen the three screws securing the power supply to the chassis and
lift the power supply to remove it from the chassis. See Figure 3-12.
