Jumpers and Connectors 153
Table 6-2. System Board Jumpers and Connectors
Item Connector Description
1 USB1
USB2
USB3
USB4 External USB connector 1
External USB connector 2
External USB connector 3
External USB connector 4
2 NIC1 External NIC connector 1
3 NIC2 External NIC connector 1
4 VGA External Video connector
5 COM External Serial connector
6 FAN Fan connector
7 PCIE_X8 PCIe connector x8 (slot 1)
8 PCIE_X16 PCIe connector x16 (slot 2)
9 PCIE_X8 PCIe connector x8 (slot 3)
10 PCIE_X1 PCIe connector x1 (slot 4)
11 PCIE_X1 PCIe connector x1 (slot 5)
12 PWRD_EN
NVRM_CLR Password enable jumper
NVRAM clear jumper
13 BATTERY System battery
14 SATA_D SATA connector D
15 SATA_C SATA connector C
16 SATA_B SATA connector B
17 SATA_A SATA connector A
18 SATA_F SATA connector F
19 INT_USB 2 Internal USB module connector 2
20 SATA_E SATA connector E
21 INT_USB 1 Internal USB module connector 1
22 BP_I2C Backplane I2C connector
