Installing System Components 91
Figure 3-10. Removing and Installing an Optical Drive
Installing an Optical Drive
CAUTION: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
with the product.
1 power and data cables 2 drive release latch
3 drive bay screw slots 4 shoulder screws (3)
5 optical drive
5
4
2
3
1
