Installing System Components 81
7 Place the system upright on a flat surface.
8 Reattach any peripherals and connect the system to an electrical outlet.
9 Turn on the system and attached peripherals.
Expansion Card Stabilizer
Removing the Expansion Card Stabilizer
1 Turn off the system and attached peripherals. Disconnect the system from
the electrical outlet and peripherals.
2 Open the system. See "Opening the System" on page 79.
3 While pressing inwards on the touch points of the expansion
card stabilizer, lift it away from the system. See Figure 3-6.
Installing the Expansion Card Stabilizer
1 Align the expansion card stabilizer with the slots on the chassis and the
cooling shroud.
2 Hold the touch points and lower the expansion card stabilizer.
See Figure 3-6.
3 Close the system. See "Closing the System" on page 80.
4 Place the system upright on a flat surface.
5 Reattach any peripherals and connect the system to an electrical outlet.
6 Turn on the system and attached peripherals.
