38

Technical Support: 1-800-4BIORAD • 1-800-424-6723 • www.bio-rad.com

6.5 Turning Analysis Off

To turn analysis off, select Analysis > Turn Analysis Off. Analysis remains off for all runs until it is
turned back on.

Turning analysis off displays the raw data from a run; it deactivates alignment, shifting the positions of
the lower marker in each sample. In addition, the pink arrows (in the virtual gel) indicating the positions
of the markers appear only in the ladder lane. With analysis off, the migration of the markers may not be
perfectly aligned (Figure 6.3). Turning analysis off can help reveal if a problem is isolated (one or a few
wells have the marker out of alignment) or is general (alignment problems across the entire chip).

Fig . 6 .3 . Effects of turning analysis off .

Analysis on

Analysis off

Experion Automated Electrophoresis System
