Technical Support: 1-800-4BIORAD • 1-800-424-6723 • www.bio-rad.com

23

All-Wells View

To display all electropherograms simultaneously (Figure 4.6):

1. In the main screen toolbar, click View All Wells

or select View > All Wells.

2. Electropherograms for each sample populate the electropherogram view (Figure 4.6). Use the

scroll bar to scroll through the electropherograms, or minimize the results and settings table to
accommodate the multiple electropherograms.

3. To select and expand a particular electropherogram, double-click on it. The data appear in a

single-well view.

Fig . 4 .5 . Single-well view . As indicated by the arrows, a single electropherogram appears, the name of the sample is highlighted
in the project tree, and the corresponding lane in the virtual gel is outlined.

Fig . 4 .6 . All-wells view .
All electropherograms
are shown in the
electropherogram view.
Use the scroll bar to view
electropherograms.
