| 101 Operating variables | H5000 Operation Manual
Polar Performance
Polar Performance displays boat speed as a percentage of the polar target for any given wind
speed and True Wind Angle.
Variable name (default)
Function name
Polar Performance (POL %)
POL PERF
Units %
Alarms N/A
Calibration N/A
Damping N/A
Pitch Rate
¼ Note:
Hydra will show this data but cannot use it.
Pitch Rate displays the current value of Pitch Rate as used by Hercules Motion for wind
correction. This function is shown for diagnostic purposes only.
¼ Note: Also see Roll Rate.
Variable name (default)
Function name
Pitch Rate
PITCH
Units Degrees per Second
Alarms N/A
Calibration N/A
Damping N/A
Rate of Turn
Rate of Turn is damped Yaw Rate for display.
Variable name (default)
Function name
Rate of Turn
TURN RTE
Units Degrees per Second
Alarms N/A
Calibration N/A
Damping N/A
Remote
n
The Remote functions are declared (in the External menu) by the Performance software and
are used to display data from an external system (e.g. a PC running B&G Deckman) via the
H-Link protocol.
