Viewing the Current Configuration
To view the current configuration programmed into the logger, click on the
View button at the bottom of the XiLog+ FastTrack application window.
Programming the Logger
1. Edit the name of the logger in the Site Name field, when necessary.
2. Edit the phone number (when applicable) in the Phone Number field.
3. Designate the parameters under the Transmission header in the
following way:
Enter the time at which the logger should transmit the data to the
host system in the Transmit Time field. The logger will send the
data at this time every day.
Select the checkbox corresponding to Auto GSM Clock
Correction to synchronize the logger clock to the time in the GSM
network every 30 days.
Select the radio button (SMS Transmission or FTP Transmission)
corresponding to the method of GSM communication that will be in
use. For SMS, enter the number for the GSM modem connected to
the host system to which the data will be sent in the Host Number
field. For FTP, enter the IP address for the server to which the data
will be sent in the Server Address field. Enter the user name and
the password necessary to access the server in the associated fields.
Note: When using the Primayer XMS System for FTP data delivery,
enter
another server, enter the IP address without the initial ftp://.
4. Designate the parameters under the Flow Channel 1 header in the
following way:
Select the type of sensor connected to Channel 1 from the Sensor
Profile drop-down list.
Enter the amount of flow that must occur to generate a pulse in the
FCAL field. Select the unit of measure for the value from the
associated drop-down list.
Enter the unit of measure in which the flow data will be reported
from the Units drop-down list.
Enter the current reading from the meter in the Meter Reading
field, and select the appropriate unit of measure from the associated
drop-down list.
