ADS XiLog+ System User Manual
23
Connected Loggers
Multiple loggers can be connected to the computer simultaneously via USB.
For multiple loggers, move among the individual logger configurations by
selecting the appropriate logger from the Connected Loggers drop-down list.
Selecting a logger displays a group of headers representing windows
corresponding to the various configuration, communication, and reporting
functions of the logger. Access the contents of a window by clicking on the
associated header.
The following windows are available, based on the selected logger:
• Communications
• Logger Information
• Installation
• Channels
• Remote Data Reporting
To create a new site, click on the Create Site button on the title bar.
Create Site dialog
Enter the name, serial number, and phone number of the new site, and select
the type of logger that will be used at the site. Completing these steps and
clicking on the Create Site button establishes the site in the PrimeWorks
database and displays the editing options for the new site.
Note: PrimeWorks displays only those headers/windows that are
applicable to the selected logger type. For example, an analog channel
window will not be available for a flow-only logger.
