ADS XiLog+ System User Manual
42
Alarm Configuration
Alarm Configuration sub-window
Alarms may be setup independently for each channel of the logger. Three
types of alarms are available: threshold, profile, and envelope alarms.
Enabled
Selecting this checkbox activates the alarms for this channel.
Profile Mode
Profile Mode menu options
This drop-down contains the options for selecting the kind of alarm to
generate from the XiLog+ under certain threshold conditions for a channel.
The following sections provide information on the individual alarm modes
and descriptions of the corresponding parameters that must be configured for
the alarms. The Common Alarm Configuration Parameters section includes
the descriptions for those parameters that are applicable to all three alarm
modes.
Common Alarm Configuration Parameters
This section describes the parameters that typically are common to all three
alarm modes.
