ADS XiLog+ System User Manual
34
Analog Channel – Generic
This window includes the parameters for setting up the generic analog
channels present on the XiLog+ 2 and XiLog+ 9 models. Three options are
available based on the channel capabilities: current, millivolt, and voltage. If
the channel can support all three options, a drop-down menu allows for
selection of the one to use.
Each option requires a different type of cable to interface to the sensor.
Generic Analog – Current (mA) example
Generic Analog – Voltage example
