ADS XiLog+ System User Manual

C H A P T E R 5

9-Channel Connections

Two options are available for wiring the outputs on the XiLog+ 9:

• NXG-302 Expansion Box
• NXG-303 Bare Wire Cable

NXG-302 Expansion Box

ADS offers an expansion box for the wiring. Make connections based on the
figures below. Seal any unused connectors on the box with a blank to prevent
damage to the connection box.
