144 YP4425A Table of Contents Index Great Plains Manufacturing, Inc.
401-805M Table of Contents Index 2012-02-23
25AP Final Meter Drive
Legend:
Sprocket or idler Tooth count
Chain Pitch count
Direction of chain in motion
34T
56P
25AP: Meter Drive (Mid type)
Note: be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
25AP: Meter Drive (Long type)
Note: be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
4
3
2
29620
19T
120P
12T
4
3
2
29621
19T
148P
12T
2
3
4
2
3
4
