Great Plains YP4425A Operator Manual User Manual
Operator manual, Manufacturing, inc

Manufacturing, Inc.
© Copyright 2012
Printed 2012-02-23
401-805M
EN
ORIGINAL INSTRUCTIONS
Operator Manual
YP4425A
44 Foot 3-Section Yield-Pro
®
Planter
with Air-Pro
®
Seed Meters
Read the operator manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit, and may
show the similar Model YP40 or YP40A, where the immediate topic applies to all.
34086
