Fertilizer carts, Pull-type fertilizer carts, Semi-mounted fertilizer carts – Great Plains YP4425A Operator Manual User Manual
Page 130: Pfc2000 tank car, Pfc1600 or pfc2000 tank car, Or use with great plains pfc1600 or pfc2000 f, The pfc1600 and pfc2000 tanks include a, Pfc2000 or pfc1600: ex, See pfc2000/pfc1600 man, Plains pfc1600 or pfc2000 tank car
126
YP4425A
Great Plains Manufacturing, Inc.
401-805M
2012-02-23
Fertilizer Carts
Pull-Type Fertilizer Carts
These tank carts were designed for use with the
YP4425A Type 3 Fertilizer manifold. The cart’s pump is
controlled by the DICKEY-john
®
seed monitor on the
planter. The PFC2000 (shown at right) is for use with
both Type 2 and Type 3 manifolds.
Use of either tank with the YP4425A requires the Trailer
Hitch Weldment and at least one Fertilizer Manifold
system.
The smaller 400 gallon tank on model PFC2000 does not
include a pump, and relies on a planter-mounted Ground
Drive Fertilizer pump (ordered separately).
Semi-Mounted Fertilizer Carts
The SML-735 and SML-500 tank carts were designed for
use with the Type 2 fertilizer manifold. These carts
require a planter-mounted Ground Drive Fertilizer pump
(purchased separately), but do not require a planter rear
pintle hitch weldment. The carts include 2-point
quick-hitch hardware for attaching to the rear seed cart
cross-tube.
Use of either tank with the YP4425A requires at least
one Fertilizer Manifold system and a planter-mounted
Ground Drive Fertilizer pump (both ordered separately).
Description
Order Number
1600 gal (6057 liter) Tank and
Pump
PFC1600
(not shown)
1600 gal (6057 liter) Tank &
Pump
w/400 gal (1514 liter) Tank
PFC2000
(shown at right top)
Description
Order Number
735 gallon (2800 liter) Tank Cart
SML-735
(shown at mid right)
510 gallon (1900 liter) Tank Cart
SML-500
(shown right bottom)
26078
31487_40%
32014
