4.05 Error Codes and remedies
Error Code
Description Cause remedy
Left
Display
right
Display
ERR 01-- This protection
circuit is activated
whenever weld
current flows in
the ground fault
protective circuit.
Fault light flashes
at a rate of
approximately 0.5
second ON, 0.5
second OFF.
Weld current is detected
running through the ground
fault protective circuit.
1. Look for metallic dust
build up between the
wirefeed plate assembly/
motor and the Wirefeeder
frame and remove the
metallic dust build up. Turn
OFF Wirefeeder then ON
again to clear ERR 01.
2. If ERR 01 appears
again with the next weld
or metallic dust build up
cannot be located then
contact your Accredited
CIGWELD Service Provider
to investigate the fault.
ERR 02-- Control cable
connecting
Wirefeeder and
Power Source not
correctly connected.
1. 19 pin plug control plug
connection is loose at either
socket on Wirefeeder or
Power Source.
2. Control cable is damaged
or has faulty connection/s.
3. Ensure that the 19 Pin
socket is selected on the
Power Source.
1. Check control cable
connections at the
Wirefeeder and Power
Source are tight.
2. If the Control Cable is
damaged then repair or
replace cable.
3. Check the Power Source
is set to 19 Pin socket
mode.
ERR 03-- Emergency
shutdown
Motor current exceeds
10amps due to seized motor
or clogged liner or filler metal
wire too big for MIG torch
liner or spool hub tension too
tight, etc.
Turn OFF Wirefeeder
then check motor / feed
mechanism can rotate
or replace liner or install
correct size liner for filler
metal or adjust spool hub
tension.
Turn ON Wirefeeder and
if ERR 03 appears again
with the next weld then
contact your Accredited
CIGWELD Service Provider
to investigate the fault.
ERR 04-- Protective shutdown Motor current exceeds
5amps for 10 seconds due to
clogged liner or filler metal
wire too big for MIG torch
liner or spool hub tension too
tight, etc.
Turn OFF Wirefeeder
then check motor / feed
mechanism can rotate
or replace liner or install
correct size liner for filler
metal or adjust spool hub
tension.
Turn ON Wirefeeder and
if ERR 04 appears again
with the next weld then
contact your Accredited
CIGWELD Service Provider
to investigate the fault.
