TRANSMIG VAF4
Manual 0-5231 2-3 INTRODUCTION
2.08 Specifications
Description Transmig VAF4 Wirefeeder
Wirefeeder Part Number W3000700
Wirefeeder Dimensions H 345mm x W 275mm x D 610mm
Wirefeeder Mass 19kg
Input Voltage 42VAC or 115VAC, 350VA
Input Voltage Tolerance ±15%
Input Frequency 50/60 Hz
Gas Solenoid Voltage 24vdc
Maximum Gas Pressure 0.7 Mpa (7 bar)
MIG Welding Output, 40°C, 10
min
450A at 60%
350A at 100%
Minimum Wire Feed Speed 1.2 - 1.5 MPM (47 - 59 IPM)
Maximum Wire Feed Speed 22.1 - 22.5 MPM (870 - 886 IPM)
Operating Temperature Range 0°C - 40°C
Interconnection Plug 19pin
Wire Sizes
Solid 0.8mm (0.030”) to 1.6mm (1/16”)
Aluminium 0.9mm (0.035”) to 1.6mm (1/16”)
Flux Cored 0.8mm (0.030”) to 2.0mm (5/64”)
Maximum Wire Spool Weight 60 lb./ 27kg
Table 2-1 Transmig VAF4 Specification
NOTE
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all
capacities, measurements, dimensions and weights quoted are approximate only. Achievable capacities
and ratings in use and operation will depend upon correct installation, use, applications, maintenance
and service.
In the interest of continuous improvement, CIGWELD Pty. Ltd. reserves the right to change the speci-
fications or design of any of its products without prior notice.
2.09 Optional Accessories
Feed Rolls
Wire Size Wire Type Part Number
0.6mm/ 0.8mm Hard 7977729
0.9mm/ 1.2mm* Hard 7977703
1.2mm/ 1.6mm Hard 7977346
0.8mm/ 0.9mm Soft 7977733
1.0mm/ 1.2mm Soft 7977730
1.2mm/ 1.6mm Soft 7977348
0.8mm/ 0.9mm Cored 7977734
1.2mm/ 1.6mm Cored 7977347
1.6mm/ 2.0mm Cored 7977372
Table 2-2 Feed Rolls
NOTE
Two feed rolls are required for each wire size.
NOTE
* indicates fitted as standard.
