TRANSMIG VAF4
Manual 0-5231
3-25
INSTALLATION, OPERATION AND SETUP
Fitting Plastic Flange to Front Panel
Replace the Front Panel and wiring as outlined in Figures 3-14 and 3-13.
Place the Tweco Plastic Flange supplied on the front panel and secure it with the M5 screws from when the
Euro adaptor front moulding was removed.
Replace the Cover Panel as outlined in Figures 3-12 and 3-11.
!
Warning
Ensure that when replacing the Front Panel and Cover Panel the earth wires are correctly and securely
connected. Also ensure that the cover panel screws have the correct star washers in place.
!
Warning
Fully tighten all fasteners.
Screw, M5
Plastic Flange, Tweco
Art # A-11369_AB
Figure 3-23 Fitting Plastic Flange to Front Panel
