Transmig vaf4 – Tweco VAF4 Transmig User Manual
Page 34
TRANSMIG VAF4
INSTALLATION, OPERATION AND SETUP
3-16
Manual 0-5231
Install the handle assembly as below:
Secure the handle assembly to the base assembly with M10 x 50 Bolts, M10 Flat Washers, M10 Spring Wash-
ers and M10 Nuts as shown in Figure 3-7.
Bolt, M10 × 50
Flat Washer, M10
Spring Washer, M10
Nut, M10
Handle Assembly
Art # A-11471_AB
Figure 3-7 Installing Handle Assembly
!
warning
Fully tighten all the fasteners with torque 45~59 N.m.
Refer to the figure below for the assembled handle assembly:
Handle Assembly
Art # A-11472_AB
Figure 3-8 Assembled Handle Assembly
