TRANSMIG VAF4
INSTALLATION, OPERATION AND SETUP 3-18 Manual 0-5231
3.13 Installing Tweco No. 4 Adaptor (Optional)
!
WARNING
There are dangerous voltage and power levels inside this product. Turn OFF wirefeeder and disconnect
from the power source before installing kit.
The following components are included in this kit:
Description Quantity
Torch Adaptor, Tweco No. 4 1
Outlet Guide 1
Set Screw, M3 ×8 1
Lock Washer, M10 1
Lock Nut, M10 1
Plastic Flange, Front 1
Flat Washer, M10 1
Spring Washer, M10 1
Hex Bolt, M10 × 15 1
Gas Hose, 220mm 1
Hose Clamp, ø 8.7 2
Wire Tie 2
4 pin- 8 pin Adaptor 1
Thumb Screw 1
Allen Key, 1.5mm 1
Allen Key, 3mm 1
Table 3-8 Tweco No 4 MIG Torch Adaptor Assembly
