Page 88

HMC-410

8-6

July 27, 2005

8.04 Parts List for the Remote Pendant

Item

Part

Description

Qty/

Application

Number

Assy

Code

170470-2

Pendant - Remote, Assembly

1

A

170470A-2

Pendant - Remote, Assembly

1

B

1

170471

Handle

1

All

2

170478

Box - Pendant

1

All

3

405535-5

.Support - PC Board

4

All

4

170468-1

.Strain - Relief

1

All

5

170479

Cable - Assembly

1

All

6

170922

Board - Remote Pendant

1

All

7

408092-9

Receptacle - 8 Pos.

1

All

8

170928

Cover

1

A

170928-1

NOTE
