HMC-410
5-8
July 27, 2005
Switch Position
1=OPEN, 0=CLOSED
Test No.
Name
Description
SSSSSSSS
12345678
26
DISPLAY LED17
LED17 (amps) is turned ON.
00101100
27
DISPLAY LED18
LED18 (arc hours x100) is turned ON.
01101100
28
DISPLAY LED19
LED19 (prog delay) is turned ON.
00011100
29
DISPLAY LED20
LED20 (weld segment) is turned ON.
01011100
30
DISPLAY LED21
LED21 (c4a) is turned ON.
00111100
31
DISPLAY SE1
Current shaft position (0 to 255) is output to
01111100
DISP B. Turning SE1 CW will increase this
number, and CCW will decrease this number.
32
DISPLAY SE2
Current shaft position (0 to 255) of SE2 is
00000010
output to DISP B. Turning SE2 CW will
increase this number, and CCW will decrease
this number.
33
DISPLAY SE3
Current shaft position (0 to 255) of SE3 is
01000010
output to DISP B. Turning SE3 CW will
increase this number, and CCW will decrease
this number.
34
DISPLAY CH5
The conversion of the Power Source
00001000
(PS SIGNATURE)
Signature’s input voltage is output to the
display board’s DISP B.
35
Display Start
Display B will display the state of the Front
01100010
Panel Start Switch. 0 = Pressed,
1 = Not Pressed
36
Display Cycle Test
Display B will display the state of the Cycle
00010010
Test Switch. 0 = Pressed, 1 = Not Pressed
37
Display Inch
Display B will display the state of the lnch
01010010
Switch. 0 = Pressed, 1 = Not Pressed
38
Display Purge
Display B will display the state of the Purge
00110010
Switches. 0 = Pressed, 1 = Not Pressed
39
Display Program/Weld Display B will display the state of the
01110010
Program/Weld Switch. 0 = Pressed,
1 = Not Pressed
40
Display Stop
Display B will display the state of the Front
00001010
Panel Stop Switch. 0 = Pressed,
1 = Not Pressed
41
Display Gun Trigger
Display B will display the state of the Gun
01001010
Trigger. 0 = Pulled, 1 = Not Pulled
42
Display Aux Seg
Display B will display the state of the Auxillary
00101010
Advance
Segement Advance. 0 = Pressed,
1 = Not Pressed
43
Display Remote Start
Display B will display the state of the Remote
01101010
Start Switch. 0 = Pressed, 1 = Not Pressed
5.06 Built In Test (BIT) Definition (continued as Table 5-1b)
