HMC-410

4-6

July 27, 2005

Software
Dash

Display Feature

Description

Settings Number

ROB

Robotic

This mode selects a robotic interface configuration as follows:

1 to 4

20+

Interface

1 - 24 Pin Direct Control (ABB)

Mode

2 - 24 Pin Master Weld On/Off Control (ABB)

Selection

3 - 37 Pin Direct Control (Fanuc)

Please see the following text for additional information on
this configuration. A 870236 kit is required for these modes
to work.

DBG

Debug

This feature will display weld error diagnostics information on

ON,

17+

the 410 when it is turned ON. The following error codes can

OFF

be displayed:

RNG: Voltage or Wire Feed Speed tolerance error
ARC: Loss of Arc Established
E C: Current error. See IL/IP softswitch description for a
more complete discussion of this mode. When this error
is displayed, the actual current readings for the first
3.5seconds of the weld are displayed in the bottom 2
displays. Scroll through the data with the middle encoder.

To return to the ready mode, the user should press the Cycle
Stop button. The error relay will stay until the unit returns to
the ready mode.

IL

Current Level This setting sets the minimum number of amps that a weld

0 to 510 17+

must achieve to be considered a ‘good’ weld. The number of
amps may be set anywhere from 0 to 510 amps. The weld
must also have this number of amps for the time set in Current
Period to be considered a ‘good’ weld. If a ‘good’ weld is not
achieved, the Error Relay will close and the Error LED on the
front of the panel is lit. If debug is turned ON, the first 3.5
seconds of the weld may be reviewed to see how the actual
weld progressed.

IP

Current

This setting sets the minimum time that a weld must remain at

0 to 25.5 17+

Period

its set Current Level to be considered a ‘good’ weld. The time
may be set from 0 to 25.5 seconds. This feature works in
conjunction with Current Level above.

SOF

Software

This number is set to the current software dash number.

Software 17+

Version

Dash
Number

DCS

Diagnostics

When this switch selects a test number, that diagnostics

1 to 64

3+

Select

routine is executed on power up. These routines are described
in detail in the Troubleshooting chapter of the manual. In order
to use the control panel operationally, this switch should be
OFF.
