8.03 Parts List for the Control Box Assembly (1 of 2)
Item Item Item Item Item Part Part Part Part Part Description Description Description Description Description Qty/ Qty/ Qty/ Qty/ Qty/ Application Application Application Application Application
Number Number Number Number Number Number Number Number Number Number Assy Assy Assy Assy Assy Code Code Code Code Code
100050-1 Box - Control, HMC-410 Assembly 1 A
100050-2 Box - Control, HMC-410 Assembly 1 B
1 170913A-1 Bracket - Mounting 2 All
2 870071 Cover - Control Box 1 A
870268 Cover - Control Box 1 B
3 204036 Label - Warning 1 All
4 870239 Wrapper - Control Box 1 All
5 870087-1 Label - Company 2 All
6 170860B-1 Board - P.C. Microprocessor - See Note 2 1 A
170860B-2 Board - P.C. Microprocessor - See Note 2 1 B
7 375426-4 Spacer - P.C. Board 6 All
8 870284 Board - PC, Control & Display 1 A
170858 Board - PC, Control & Display 1 B
9 375426-1 Spacer - P.C. Board 6 All
10 170916B Overlay - Control Panel 1 All
11 406807-6 Knob - Control 4 All
12 408971-1 Switch - Program/Weld 1 All
13 403091-12 Plug - Hole 2 All
14 870032-3 Switch - Rocker Arm, Circuit Breaker 1 All
15 171138-1 Transformer - Control 1 All
16 409838 Grommet - Mounting 4 All
17 409837 Spacer - Mounting 4 All
18 170869C-1 Board - P.C., Interface/Suppressor 1 All
19 830116 Label - Ground 1 All
20 See Note 1 Screw - 1/4-20 x 7/8 Hex Head Med Hard Steel 1 All
21 See Note 1 Washer - 1/4, Lock 1 All
22 See Note 1 Nut - 1/4-20, Keps 2 All
23 See Note 1 Washer - 1/4, Flat 1 All
24 170862A Board - P.C., Motor Control 1 All
25 870294 Label - Amphenol 1 All
26 W-11166-10 Fuse - AGC3, 3 Amp 2 All
27 375426-11 Spacer - P.C. Board 5 All
28 No Number Label - CSA NRTL/C 1 All
29 204038-2 Cable - Ribbon Assembly 2 All
NOTES:
1. This part may be purchased locally.
2. When ordering this board, please verify that any installed software options are also ordered. Refer to the
Controller Board Software on page 2-16 for more information.
