5.2 Standard equipment
Subject to changes!
All dimensions are given in mm.
The 2.793.0010 Sample Prep Module includes the following parts:
Quant. Order No. Description
1 1.793.0010 IC Sample Prep Module
1 1.793.0110 SP Module A
1 6.1803.020 PTFE capillary tubing
Length = 5 m
2 6.1826.010 Pump tubing
made of PVC (Tygon £ ); with 2 firmly
attached white-white stoppers;
i.d. = 1.02 mm, e.d. = 2.72 mm
400
150
1 6.2122.0X0 Mains cable
to customer's specifications:
Cable socket Cable
connector
Type IEC 320/C 13 Type SEV 12 (CH}) ........................... 6.2122.020
Type IEC 320/C 13 Type CEE (7), VII (D}) ....................... 6.2122.040
Type CEE (22), V Type NEMA 5-15 (USA}) .................. 6.2122.070
2 6.2128.180 Connecting cable
Connecting cable 762 IC Interface –
752, 753, 754, or 793
2 6.2744.010 PEEK compression fitting
For the connection of capillaries (
1
e 16
") ,
set of 5 pcs
26
1 6.2744.030 PEEK coupling
Connection between 6.2744.010 PEEK
compression fitting and 6.1826.0X0
pump tubing (also supplied together with
733.0030 IC Separation Center);
Set of 4 pcs
1 6.2744.040 PEEK coupling
For the connection of capillaries (
1
e 16
")
1.57 0.97
25
9.5
24
