98 Bendix Spicer Foundation Brakes LLC • 901 Cleveland Street • Elyria, OH 44035 • 1-866-610-9709 • www.foundationbrakes.com
Spider
Stamped Spider and Pin Assembly 16.5" (pages 96–100)
For Models: EB-165 & ES-165
“A”
“B”
“C”
“D”
Part No.
Spider &
Pilot
Bolt
No. of Holes
Mtg.
Mtg. Hole
on Piece
Pin Assembly
Diameter
Circle
& Pattern
Index Angle
Diameter
815728
815728
5.504 (139.802)
7.250 (184.150)
8 Steer
75°
0.659 (16.739)
815729
815729
5.504 (139.802)
7.250 (184.150)
8 Steer
285°
0.659 (16.739)
862
815862
6.755 (171.577)
8.250 (209.550)
10 On 16
22.5°
0.659 (16.739)
863
815863
6.755 (171.577)
8.250 (209.550)
10 On 16
22.5°
0.659 (16.739)
816016
816016
5.504 (139.802)
7.250 (184.150)
7 Steer
53°
0.659 (16.739)
816017
816017
5.504 (139.802)
7.250 (184.150)
7 Steer
307°
0.659 (16.739)
138
816138
6.618 (168.097)
7.598 (192.989)
11 On 12
12°
0.576 (14.630)
139
816139
6.618 (168.097)
7.598 (192.989)
11 On 12
18°
0.576 (14.630)
816144
816144
5.755 (146.177)
7.250 (184.150)
8 Steer
57°
0.784 (19.914)
816145
816145
5.755 (146.177)
7.250 (184.150)
8 Steer
303°
0.784 (19.914)
816154
816154
5.504 (139.802)
7.250 (184.150)
8 Steer
45°
0.659 (16.739)
816155
816155
5.504 (139.802)
7.250 (184.150)
8 Steer
315°
0.659 (16.739)
344
816344
6.755 (171.577)
8.125 (206.375)
10 Equally Spc
13°
0.659 (16.739)
345
816345
6.755 (171.577)
8.125 (206.375)
10 Equally Spc
23°
0.659 (16.739)
898
816898
6.755 (171.577)
8.250 (209.550)
15 On 16
0°
0.659 (16.739)
899
816899
6.755 (171.577)
8.250 (209.550)
15 On 16
0°
0.659 (16.739)
946
816946
6.755 (171.577)
8.250 (209.550)
15 On 16
4.5°
0.659 (16.739)
947
816947
6.755 (171.577)
8.250 (209.550)
15 On 16
18°
0.659 (16.739)
025
817025
6.755 (171.577)
8.125 (206.375)
10 Equally Spc
0°
0.659 (16.739)
817504
817504
5.504 (139.802)
7.250 (184.150)
8 Steer
69°
0.659 (16.739)
817505
817505
5.504 (139.802)
7.250 (184.150)
8 Steer
291°
0.659 (16.739)
858
817858
6.755 (171.577)
8.125 (206.375)
9 On 10
18°
0.659 (16.739)
859
817859
6.755 (171.577)
8.125 (206.375)
9 On 10
18°
0.659 (16.739)
022
818022
6.755 (171.577)
8.250 (209.550)
15 On 16
8.5°
0.659 (16.739)
023
818023
6.755 (171.577)
8.250 (209.550)
15 On 16
14°
0.659 (16.739)
392
818392
6.755 (171.577)
8.250 (209.550)
10 On 16
32.5°
0.659 (16.739)
393
818393
6.755 (171.577)
8.250 (209.550)
10 On 16
12.5°
0.659 (16.739)
394
818394
6.755 (171.577)
8.250 (209.550)
10 On 16
6.5°
0.659 (16.739)
395
818395
6.755 (171.577)
8.250 (209.550)
10 On 16
38.5°
0.659 (16.739)
818586
818586
5.504 (139.802)
7.250 (184.150)
8 Steer
36°
0.659 (16.739)
818587
818587
5.504 (139.802)
7.250 (184.150)
8 Steer
324°
0.659 (16.739)
610
818610
6.003 (152.476)
7.375 (187.325)
6 Steer
62°
0.659 (16.739)
611
818611
6.003 (152.476)
7.375 (187.325)
6 Steer
118°
0.659 (16.739)
612
818612
6.003 (152.476)
7.375 (187.325)
6 Steer
62°
0.659 (16.739)
613
818613
6.003 (152.476)
7.375 (187.325)
6 Steer
118°
0.659 (16.739)
618
818618
6.755 (171.577)
8.250 (209.550)
15 On 16
11.5°
0.659 (16.739)
619
818619
6.755 (171.577)
8.250 (209.550)
15 On16
11°
0.659 (16.739)
818670
818670
5.504 (139.802)
7.250 (184.150)
7 Steer
45°
0.659 (16.739)
818671
818671
5.504 (139.802)
7.250 (184.150)
7 Steer
315°
0.659 (16.739)
818864
818864
5.504 (139.802)
7.250 (184.150)
8 Steer
57°
0.659 (16.739)
818865
818865
5.504 (139.802)
7.250 (184.150)
8 Steer
303°
0.659 (16.739)
