“A” “B” “C” “D”
Standard Gussetted Bracket Angle Barrel Length Slack Length Offset
Part No. Part No. Bracket Type in (mm) in (mm) in (mm)
806014 N/A 70 CCW 17.31 5.0 - 5.5 1.75
806015 N/A 70 CW (439.750) (127 - 140) (44.450)
806572 N/A 85 CCW 17.31 5.5 - 6.0 1.75
806573 N/A 85 CW (439.750) (140 - 152) (44.450)
819930 N/A 90 CCW 17.31 5.5 - 6.0 1.75
819931 N/A 90 CW (439.750) (140 - 152) (44.450)
N/A 818492 82 CCW 17.75 5.5 - 6.0 1.75
N/A 818493 82 CW (450.850) (140 - 152) (44.450)
974112 N/A 50 CCW 18.81 5.5 - 6.0 1.75
974113 N/A 50 CW (477.850) (140 - 152) (44.450)
819532 N/A 70 CCW 18.81 5.5 - 6.0 1.75
819533 N/A 70 CW (477.850) (140 - 152) (44.450)
N/A 975546 70 CCW 18.81 5.0 1.75
N/A 975547 70 CW (477.850) (127) (44.450)
814596 N/A 85 CCW 18.81 5.5 - 6.0 1.75
814597 N/A 85 CW (477.850) (140 - 152) (44.450)
N/A 975126 48 CCW 19.75 5.5 - 6.0 1.75
N/A 975127 48 CW (501.650) (140 - 152) (44.450)
819932 974846 85 CCW 19.75 5.5 - 6.0 1.75
819933 974847 85 CW (501.650) (140 - 152) (44.450)
Brackets for Stamped Spider
Air Chamber Mounting Brackets 16.5" – Standard and Extended Service Brakes w/ Stamped Spider
(pages 37–57)
(Brackets For Cast Spider See Pages 58-80)
For Models: EB-165-5L, 6L, 7L, 8L & ES-165-5L, 6L, 7L, 8L
