Brackets for Stamped Spider

“A”

“B”

“C”

“D”

Standard

Gussetted

Bracket Angle

Barrel Length

Slack Length

Offset

Part No.

Bracket Type

in (mm)

N/A

817918

48 CCW

12.56

5.5 - 6.0

1.75

N/A

817919

48 CW

(319.150)

(140 - 152)

(44.450)

808916

N/A

53 CCW

12.56

5.5 - 6.0

1.75

808917

N/A

53 CW

(319.150)

(140 - 152)

(44.450)

N/A

812760

53 CCW

12.56

5.5 - 6.0

1.75

N/A

812761

53 CW

(319.150)

(140 - 152)

(44.450)

812716

N/A

55 CCW

12.56

5.5 - 6.0

1.75

812717

N/A

55 CW

(319.150)

(140 - 152)

(44.450)

N/A

814942

55 CCW

12.56

5.5 - 6.0

1.75

N/A

814943

55 CW

(319.150)

(140 - 152)

(44.450)

807104

N/A

60 CCW

12.56

5.5 - 6.0

1.75

807105

N/A

60 CW

(319.150)

(140 - 152)

(44.450)

808404

N/A

63 CCW

12.56

5.0 - 5.5

1.75

808405

N/A

63 CW

(319.150)

(127 - 140)

(44.450)

819666

N/A

63 CCW

12.56

5.5 - 6.0

1.75

819667

N/A

63 CW

(319.150)

(140 - 152)

(44.450)

N/A

814922

63 CCW

12.56

5.0 - 5.5

1.75

N/A

814923

63 CW

(319.150)

(127 - 140)

(44.450)

N/A

819668

63 CCW

12.56

5.5 - 6.0

1.75

N/A

819669

63 CW

(319.150)

(140 - 152)

(44.450)

808918

N/A

65 CCW

12.56

5.5 - 6.0

1.75

808919

N/A

65 CW

(319.150)

(140 - 152)

(44.450)

N/A

812766

65 CCW

12.56

5.5 - 6.0

1.75

N/A

812767

65 CW

(319.150)

(140 - 152)

(44.450)

809948

N/A

69 CCW

12.56

5.5 - 6.0

1.75

809949

N/A

69 CW

(319.150)

(140 - 152)

(44.450)

N/A

817920

69 CCW

12.56

5.5 - 6.0

1.75

N/A

817921

69 CW

(319.150)

(140 - 152)

(44.450)

812732

814944

80 CCW

12.56

5.5 - 6.0

1.75

812733

814945

80 CW

(319.150)

(140 - 152)

(44.450)

814660

814944

80 CCW

12.56

5.5 - 6.0

1.75

814661

814945

80 CW

(319.150)

(140 - 152)

(44.450)

810798

812776

90 CCW

12.56

5.5 - 6.0

1.75

810799

812777

90 CW

(319.150)

(140 - 152)

(44.450)

N/A

814928

90 CCW

12.56

5.0 - 5.5

1.75

N/A

814929

90 CW

(319.150)

(127 - 140)

(44.450)

807760

N/A

95 CCW

12.56

5.5 - 6.0

1.75

807761

N/A

95 CW

(319.150)

(140 - 152)

(44.450)

804444

N/A

30 CCW

12.81

5.5 - 6.0

1.75

804445

N/A

30 CW

(325.450)

(140 - 152)

(44.450)

N/A

812758

30 CCW

12.81

5.5 - 6.0

1.75

N/A

812759

30 CW

(325.450)

(140 - 152)

(44.450)

804442

N/A

55 CCW

12.81

5.5 - 6.0

1.75

804443

N/A

55 CW

(325.450)

(140 - 152)

(44.450)

Air Chamber Mounting Brackets 16.5" – Standard and Extended Service Brakes w/ Stamped Spider

(pages 37–57)

(Brackets For Cast Spider See Pages 58-80)

For Models: EB-165-5L, 6L, 7L, 8L & ES-165-5L, 6L, 7L, 8L
