Spider
Stamped Spider and Pin Assembly 16.5" (pages 96–100)
For Models: EB-165 & ES-165
“A”
“B”
“C”
“D”
Part No.
Spider &
Pilot
Bolt
No. of Holes
Mtg.
Mtg. Hole
on Piece
Pin Assembly
Diameter
Circle
& Pattern
Index Angle
Diameter
103
974103
6.755 (171.577)
8.250 (209.550)
8 On 16
52.5°
0.659 (16.739)
104
974104
6.755 (171.577)
8.250 (209.550)
8 On 16
12°
0.659 (16.739)
105
974105
6.755 (171.577)
8.250 (209.550)
8 On 16
55.5°
0.659 (16.739)
106
974106
6.755 (171.577)
8.250 (209.550)
8 On 16
12.5°
0.659 (16.739)
107
974107
6.755 (171.577)
8.250 (209.550)
8 On 16
55°
0.659 (16.739)
298
974298
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
31°
0.659 (16.739)
299
974299
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
14°
0.659 (16.739)
300
974300
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
40.5°
0.659 (16.739)
301
974301
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
4.5°
0.659 (16.739)
302
974302
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
22.5°
0.659 (16.739)
303
974303
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
22.5°
0.659 (16.739)
304
974304
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
33.5°
0.659 (16.739)
305
974305
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
11.5°
0.659 (16.739)
306
974306
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
40.5°
0.659 (16.739)
307
974307
6.755 (171.577)
8.250 (209.550)
8 Equally Spc
4.5°
0.659 (16.739)
974400
974400
5.755 (146.177)
7.250 (184.150)
7 Steer
45°
0.784 (19.914)
974401
974401
5.755 (146.177)
7.250 (184.150)
7 Steer
315°
0.784 (19.914)
440
974440
6.755 (171.577)
8.125 (206.375)
10 Equally Spc
0°
0.659 (16.739)
974552
974552
5.755 (146.177)
7.250 (184.150)
7 Steer
62.5°
0.784 (19.914)
974553
974553
5.755 (146.177)
7.250 (184.150)
7 Steer
297.5°
0.784 (19.914)
974732
974732
5.755 (146.177)
7.250 (184.150)
7 Steer
67°
0.784 (19.914)
974733
974733
5.755 (146.177)
7.250 (184.150)
7 Steer
293°
0.784 (19.914)
974752
974752
5.504 (139.802)
7.250 (184.150)
7 Steer
315°
0.659 (16.739)
974753
974753
5.504 (139.802)
7.250 (184.150)
7 Steer
45°
0.659 (16.739)
974952
974952
5.504 (139.802)
7.250 (184.150)
7 Steer
60°
0.659 (16.739)
974953
974953
5.504 (139.802)
7.250 (184.150)
7 Steer
300°
0.659 (16.739)
975022
975022
5.504 (139.802)
7.250 (184.150)
7 Steer
57°
0.659 (16.739)
975023
975023
5.504 (139.802)
7.250 (184.150)
7 Steer
303°
0.659 (16.739)
242
975242
6.755 (171.577)
8.250 (209.550)
16 Equally Spc
20°
0.659 (16.739)
243
975243
6.755 (171.577)
8.250 (209.550)
16 Equally Spc
2.5°
0.659 (16.739)
340
975340
5.504 (139.802)
7.250 (184.150)
7 Steer
62°
0.659 (16.739)
341
975341
5.504 (139.802)
7.250 (184.150)
7 Steer
298°
0.659 (16.739)
