Spider
Cast Spider and Pin Assembly 16.5" (pages 101–102)
For Models: EB-165, ES-165 & ES-150-4D
“C”
“A”
“B”
Number/Size “D”
“E”
Pilot Dia.
Bolt Circle
of Mtg. Holes
Mtg. Hole
Brake Offset
Part No.
Casting No.
in (mm)
in (mm)
in (mm)
Index Angle
in (mm)
68436
68400
5.750 (146.050)
7.750 (196.850)
16/.594 (15.088)
0°
1.31 (33.274)
74706
70540
5.880 (149.352)
7.125 (180.975)
16/.594 (15.088)
30°
.906 (23.012)
2/.563
(14.300)
-12
UNC-3B
1001948
70540
5.880 (149.352)
7.125 (180.975)
11/.594 (15.088)
35°
.906 (23.012)
1001949
70540
5.880 (149.352)
7.125 (180.975)
11/.594 (15.088)
25°
.906 (23.012)
1006130
821735
6.000 (152.400)
7.250 (184.150)
8/.656 (16.662)
15°
1.31 (33.274)
1006131
821735
6.000 (152.400)
7.250 (184.150)
8/.656 (16.662)
11°
1.31 (33.274)
1008086
821763
6.310 (160.274)
8.375 (212.725)
8/.656 (16.662)
8.5°
2.50 (63.500)
1/.750
(19.050)
1008087
821763
6.310 (160.274)
8.375 (212.725)
8/.656 (16.662)
18°
2.50 (63.500)
1/.750
(19.050)
1001039
79900
6.750 (171.450)
8.125 (206.375)
9/.656 (16.662)
11°
1.750 (44.450)
1/1
(25.400)
1001040
79900
6.750 (171.450)
8.125 (206.375)
9/.656 (16.662)
18°
1.750 (44.450)
1/1
(25.400)
1000871
79900
6.750 (171.450)
8.125 (206.375)
10/.656 (16.662)
18°
1.750 (44.450)
1000872
79900
6.750 (171.450)
8.125 (206.375)
10/.656 (16.662)
18°
1.750 (44.450)
79935
79900
6.750 (171.450)
8.250 (209.550)
16/.656 (16.662)
0°
1.750 (44.450)
1001638
79900
6.750 (171.450)
8.250 (209.550)
8/.656 (16.662)
32.5°
1.750 (44.450)
2/.750
(19.050)
1001639
79900
6.750 (171.450)
8.250 (209.550)
8/.656 (16.662)
12.5°
1.750 (44.450)
2/.750
(19.050)
1001698
79900
6.750 (171.450)
8.125 (206.375)
9/.656 (16.67)
24°
1.750 (44.450)
1/1
(25.400)
