Bendix Spicer Foundation Brakes LLC • 901 Cleveland Street • Elyria, OH 44035 • 1-866-610-9709 • www.foundationbrakes.com 21
Brake Shoe
Extended Service Brake Shoe and Lining Chart (pages 21–23)
Brake Size Shoe Part Type Lining Shoe & Major Overhaul Kit Major Overhaul Kit Brake
No. Shoe Type Lining Assy w/o Horse Collar w/Horse Collar Lining Kit
15 x 4 807685 ES EES400 807684 811745 (1.5" Offset) 811907
Extended Service 811746 (2.0" Offset) 811907
ES-150-4L EES410 818569 314966 (1.5" Offset) 317214
FMSI 1443 EES420 818570 317202 (1.5" Offset) 328339
317203 (2.0" Offset) 328339
EES600 974924 326512 (1.5" Offset) 328340
326513 (2.0" Offset) 328340
EES560 974524 318338 (1.5" Offset) 318337
318339 (2.0" Offset) 318337
15 x 4 974584 ESII EES600 974587 326517 326515
Extended Service EES420 974588 328322 328337
ES-150-4D EES560 974589 328323 328338
EES440 974848 326518 326516
ES450S 975507 327842 328336
15 x 6 819716 ESII EES200 816083 823142 823139
Extended Service EES300 816082 823143 823140
ES-150-6L, D EES310 974236 325394 325633
FMSI 4716
Reduced Envelope
15 x 8.63 819718 ESII EES200 815082 815625 815628
Extended Service EES300 816871 824906 823145
ES-150-8D, F EES310 974238 325395 325633
FMSI 4717
Reduced Envelope
16.5 x 5 819705 ESII EES400 819750 317688 314156 823759
Extended Service EES410 819752 317689 314157 314163
ES-165-5L,D EES420 819754 317690 314158 314164
FMSI 4719 EES440 974855 326744 327045 326740
EES450 974998 328317 328314 328330
EES560 974526 318341 318342 318340
EES600 819756 317691 314159 823760
EES670 975094 327847 327843 328329
EES1050 975020 328318 328315 328328
EES1100 819511 317692 314160 823761
EES1200 819513 317693 314161 314165
EES1100/600 974319 328316 328313 823761
EES1200/410 819725 317694 314162 314166
