Spider
Stamped Spider and Pin Assembly 15" x 4" (pages 91–93)
For Models: EB-150-4L & ES-150-4L
“C”
Part No. “A” “B” “C” Mtg. Hole “D” Brake
Stamped Pilot Diameter Bolt Circle No. of Holes Diameter Mtg. Offset
on Piece Part No. in (mm) in (mm) & Pattern in (mm) Index Angle in (mm) Remarks
163 819163 5.003 (127.076) 6.000 (152.400) 8 Steer 0.534 (13.564) 306 1.500 (38.100)
184 1008184 6.003 (152.476) 7.375 (187.325) 6 Steer 0.659 (16.739) 62° 1.990 (50.546)
185 1008185 6.003 (152.476) 7.375 (187.325) 6 Steer 0.659 (16.739) 298° 1.990 (50.546)
186 811186 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 65° 1.500 (38.100)
187 811187 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 295° 1.500 (38.100)
192 974192 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 62° 1.500 (38.100)
193 974193 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 298° 1.500 (38.100)
228 1008228 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 65° 1.500 (38.100)
229 1008229 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 295° 1.500 (38.100)
236 818236 6.003 (152.476) 7.375 (187.325) 6 Steer 0.659 (16.739) 326° 1.990 (50.546)
237 818237 6.003 (152.476) 7.375 (187.325) 6 Steer 0.659 (16.739) 34° 1.990 (50.546)
242 1008242 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 291° 1.500 (38.100)
243 1008243 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 69° 1.500 (38.100)
310 811310 5.503 (139.776) 6.437 (163.499) 8 Steer 0.659 (16.739) 275° 1.500 (38.100)
311 811311 5.503 (139.776) 6.437 (163.499) 8 Steer 0.659 (16.739) 85° 1.500 (38.100)
354 811354 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 69° 1.500 (38.100)
355 811355 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 291° 1.500 (38.100)
418 1006418 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 86.5° 1.500 (38.100)
436 974436 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 45° 1.500 (38.100)
437 974437 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 315° 1.500 (38.100)
456 812456 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 300° 1.500 (38.100)
457 812457 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 60° 1.500 (38.100)
474 815474 6.003 (152.476) 7.250 (184.150) 7 Steer 0.659 (16.739) 62° 1.500 (38.100) FOR INTERNATIONAL TRUCK
AND ENGINE SERVICE ONLY
475 815475 6.003 (152.476) 7.250 (184.150) 7 Steer 0.659 (16.739) 298° 1.500 (38.100) FOR INTERNATIONAL TRUCK
AND ENGINE SERVICE ONLY
480 810480 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 300° 1.500 (38.100)
481 810481 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 60° 1.500 (38.100)
510 974510 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 315° 1.500 (38.100)
511 974511 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 45° 1.500 (38.100)
560 974560 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 302° 1.500 (38.100)
561 974561 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 58° 1.500 (38.100)
566 974566 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 58° 1.500 (38.100)
567 974567 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 302° 1.500 (38.100)
568 974568 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 58° 1.500 (38.100)
569 974569 5.503 (139.776) 7.250 (184.150) 8 Steer 0.659 (16.739) 302° 1.500 (38.100)
578 810578 5.629 (142.977) 7.437 (188.899) 4 Square 0.784 (19.914) 90° 1.990 (50.546)
579 810579 5.629 (142.977) 7.437 (188.899) 4 Square 0.784 (19.914) 270° 1.990 (50.546)
590 811590 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 68° 1.500 (38.100)
591 811591 5.503 (139.776) 7.250 (184.150) 7 Steer 0.659 (16.739) 292° 1.500 (38.100)
