Bendix Commercial Vehicle Systems ILLUSTRATED PARTS LIST BRAKES User Manual
Page 85
84 Bendix Spicer Foundation Brakes LLC • 901 Cleveland Street • Elyria, OH 44035 • 1-866-610-9709 • www.foundationbrakes.com
“A”
“B”
“C”
“D”
Gussetted
Bracket
Angle
Barrel
Length
Slack
Length
Offset
Part No.
Bracket Type
in (mm)
in (mm)
in (mm)
973762 72
CCW 10.25
5.5-6.0 1.75
973763
72 CW
(260.350)
(140-152)
(44.450)
816530 78
CCW 10.25
5.5-6.0 1.75
816531
78 CW
(260.350)
(140-152)
(44.450)
817764 95
CCW 10.25
5.5-6.0 1.75
817765
95 CW
(260.350)
(140-152)
(44.450)
817766 105
CCW
10.25
5.5-6.0 1.75
817767 105
CW
(260.350) (140-152)
(44.450)
809652 315
CCW
10.25
5.5-6.0 1.75
809653 315
CW
(260.350) (140-152)
(44.450)
811650 45
CCW 10.56
5.5-6.0 1.75
811651
45 CW
(268.300)
(140-152)
(44.450)
811648 69
CCW 10.56
5.5-6.0 1.75
811649
69 CW
(268.300)
(140-152)
(44.450)
819436 0
CCW 10.75
5.5-6.0 1.75
819437 0
CW (273.050) (140-152)
(44.450)
819892 50
CCW 10.75
5.5-6.0 1.75
819893
50 CW
(273.050)
(140-152)
(44.450)
814784 69
CCW 10.75
5.5-6.0 1.75
814785
69 CW
(273.050)
(140-152)
(44.450)
819434 75
CCW 10.75
5.5-6.0 1.75
819435
75 CW
(273.050)
(140-152)
(44.450)
974134 80
CCW 10.75
5.5-6.0 1.75
974135
80 CW
(273.050)
(140-152)
(44.450)
816232 90
CCW 10.75
5.5-6.0 1.75
816233
90 CW
(273.050)
(140-152)
(44.450)
974032 113
CCW
10.75
5.5-6.0 1.75
974033
113 CW
(273.050)
(140-152)
(44.450)
973918 53
CCW 11.22
5.5-6.0 1.75
973919
53 CW
(284.960)
(140-152)
(44.450)
815650 56
CCW 11.22
5.5-6.0 1.75
815651
56 CW
(284.960)
(140-152)
(44.450)
817256 60
CCW 11.22
5.5-6.0 1.75
817257
60 CW
(284.960)
(140-152)
(44.450)
974282 65
CCW 11.22
5.5-6.0 1.75
974283
65 CW
(284.960)
(140-152)
(44.450)
811950 69
CCW 11.22
5.5-6.0 1.75
811951
69 CW
(284.960)
(140-152)
(44.450)
810118 72
CCW 11.22
5.5-6.0 1.75
810119
72 CW
(284.960)
(140-152)
(44.450)
975748 74
CCW 11.22
5.5-6.0 1.75
975749
74 CW
(284.960)
(140-152)
(44.450)
811986 75
CCW 11.22
5.5-6.0 1.75
811987
75 CW
(284.960)
(140-152)
(44.450)
Air Chamber Mounting Brackets 16.5" x 7" – Extended Service Brakes w/ Dual Anchor Pin Cast Spider
(pages 81–87)
For Models: ES-165-7M & ES-165-7H
Brackets
