Page 95
94 Bendix Spicer Foundation Brakes LLC • 901 Cleveland Street • Elyria, OH 44035 • 1-866-610-9709 • www.foundationbrakes.com
Spider
Cast Spider and Pin Assembly 15" x 6"
For Model: ES-150-6D
A
B
C
E
D
Offset
CL
Vertical
of Axle
CL of Cam
“D”
Centerline “E”
“A”
“B” “C” “C”
of
Cam Brake
Standard
Vehicle
Pilot Dia.
Bolt Circle
Number of
Hole Size
to Vert.
Offset
Part No.
Position
in (mm)
in (mm)
Holes
in (mm)
Centerline
in (mm)
Remarks
816072
LH
5.504 (139.802)
7.250 (184.150)
8
.653 (16.586)
297°
1.750 (44.450)
816073
RH
8
63°
816806
LH
5.504 (139.802)
7.250 (184.150)
8
.653 (16.586)
63°
1.750 (44.450)
816807
RH
8
297°
819950
LH
5.504 (139.802)
7.250 (184.150)
8
.653 (16.685)
297°
1.750 (44.450)
Has 2 ABS Slots
819951
RH
8
63°
Has 2 ABS Slots
