Brackets
Air Chamber Mounting Brackets 15" x 4" – Standard and Extended Ser vice Brakes (pages 30–32)
For Models: EB-150-4L & ES-150-4L
“A” “B” “C” “D”
Standard Bracket Angle Barrel Length Slack Length Offset
Part No. Bracket T ype in (mm) in (mm) in (mm)
974066 306 CCW 7.62 5.5 1.50
974067 306 CW (193.472) (140) (38.100)
975192 323 CCW 7.62 5.5 1.50
975193 323 CW (193.472) (140) (38.100)
818994 323 CCW 7.39 5.5 1.50
818995 323 CW (187.655) (140) (38.100)
975388 323 CCW 8.39 5.5 1.50
975389 323 CW (213.055) (140) (38.100)
811954 58 CCW 8.73 5.5 1.50
811955 58 CW (221.793) (140) (38.100)
811858 69 CCW 8.73 5.5 1.50
811859 69 CW (8.732) (140) (38.100)
815362 90 CCW 8.73 5.5 1.50
815363 90 CW (8.732) (140) (38.100)
809746 130 CCW 8.73 5.5 1.50
809747 130 CW (8.732) (140) (38.100)
815314 300 CCW 8.73 5.5 1.50
815315 300 CW (8.732) (140) (38.100)
1006856 308 CCW 8.73 5.5 1.50
1006857 308 CW (8.732) (140) (38.100)
1006860 323 CCW 8.73 5.5 1.50
1006861 323 CW (8.732) (140) (38.100)
809152 334 CCW 8.73 5.5 1.50
809153 334 CW (8.732) (140) (38.100)
1008244 144 CCW 8.96 5.5 1.50
1008245 144 CW (227.203) (140) (38.100)
