Bendix Commercial Vehicle Systems ILLUSTRATED PARTS LIST BRAKES User Manual
Page 67
66 Bendix Spicer Foundation Brakes LLC • 901 Cleveland Street • Elyria, OH 44035 • 1-866-610-9709 • www.foundationbrakes.com
Brackets with Cast Spider
“A”
“B”
“C”
“D”
Standard
Gussetted
Bracket Angle
Barrel Length
Slack Length
Offset
Part No.
Part No.
Bracket Type
in (mm)
in (mm)
in (mm)
N/A
811212
69 CCW
9.31
5.5
1.75
N/A
811213
69 CW
(236.550)
(140)
(44.450)
1001432 N/A
69
CCW
9.31
6.0-6.5 1.75
1001433
N/A
69 CW
(236.550)
(152-165)
(44.450)
1003436
813276
69 CCW
9.31
5.5-6.0
1.75
1003437
813277
69 CW
(236.550)
(140-152)
(44.450)
1004002
813276
69 CCW
9.31
5.5-6.0
1.75
1004003
813277
69 CW
(236.550)
(140-152)
(44.450)
89734 N/A
69
CCW
9.31 6.0-6.5 2.81
89735
N/A
69 CW
(236.550)
(152-165)
(71.374)
89800 N/A
70
CCW
9.31 5.5-6.0 2.81
89801 N/A
70
CW
(236.550)
(140-152)
(71.374)
82592 N/A
72
CW
9.31 6.0-6.5 1.75
82593 N/A
72
CCW
(236.550)
(152-165)
(44.450)
1001709 N/A
72
CCW
9.31
6.0-6.5 1.75
1001710
N/A
72 CW
(236.550)
(152-165)
(44.450)
1003726
809686
72 CCW
9.31
5.5-6.0
1.75
1003727
809687
72 CW
(236.550)
(140-152)
(44.450)
N/A 816876
72
CCW
9.31 5.5-6.0
1.75
N/A
816877
72 CW
(236.550)
(140-152)
(44.450)
74720 N/A
75
CCW
9.31 6.0-6.5 1.75
74721
N/A
75 CW
(236.550)
(152-165)
(44.450)
1005974
812650
75 CCW
9.31
5.5-6.0
1.75
1005975
812651
75 CW
(236.550)
(140-152)
(44.450)
808966
812650
75 CCW
9.31
5.5-6.0
1.75
808967
812651
75 CW
(236.550)
(140-152)
(44.450)
N/A 975426
76
CCW
9.31 5.5 1.75
N/A
975427
76 CW
(236.550)
(140)
(44.450)
1004898 N/A
76
CCW
9.31
5.5-6.0 1.75
1004899
N/A
76 CW
(236.550)
(140-152)
(44.450)
N/A 814870
77
CCW
9.31 5.5-6.0
1.75
N/A
814871
77 CW
(236.550)
(140-152)
(44.450)
975718 N/A
78
CCW
9.31 5.5-6.0 1.75
975719
N/A
78 CW
(236.550)
(140-152)
(44.450)
1008804 N/A
78
CCW
9.31
6.0-6.5 2.50
1008805
N/A
78 CW
(236.550)
(152-165)
(63.500)
89412 N/A
79
CW
9.31 6.0-6.5 1.75
89413 N/A
79
CCW
(236.550)
(152-165)
(44.450)
N/A
811214
80 CCW
9.31
5.5
1.75
N/A
811215
80 CW
(236.550)
(140)
(44.450)
1006666
813072
80 CCW
9.31
5.5-6.0
1.75
1006667
813073
80 CW
(236.550)
(140-152)
(44.450)
N/A 818138
80
CCW
9.31 5.5-6.0
2.50
N/A
818139
80 CW
(236.550)
(140-152)
(63.500)
Air Chamber Mounting Brackets 16.5" – Standard and Extended Service Brakes w/ Cast Spider
(pages 58–80)
(Brackets w/Stamped Spider See Pages 37-57)
For Models: EB-165-5D, 6D, 7D, 8D, 8F & ES-165-5D, 6D, 7D, 8D, 8F
