56 Bendix Spicer Foundation Brakes LLC • 901 Cleveland Street • Elyria, OH 44035 • 1-866-610-9709 • www.foundationbrakes.com

Brackets for Stamped Spider

“A”

“B”

“C”

“D”

Standard

Gussetted

Bracket Angle

Barrel Length

Slack Length

Offset

Part No.

Bracket Type

in (mm)

806656

N/A

96 CCW

14.69

5.5 - 6.0

1.75

806657

N/A

96 CW

(373.150)

(140 - 152)

(44.450)

806818

N/A

101 CCW

14.69

5.5 - 6.0

1.75

806819

N/A

101 CW

(373.150)

(140 - 152)

(44.450)

805786

N/A

321 CCW

14.69

5.5 - 6.0

1.75

805787

N/A

321 CW

(373.150)

(140 - 152)

(44.450)

819528

N/A

55 CCW

15.44

5.5 - 6.0

1.75

819529

N/A

55 CW

(392.150)

(140 - 152)

(44.450)

N/A

975394

55 CCW

15.44

5.5 - 6.0

1.75

N/A

975395

55 CW

(392.150)

(140 - 152)

(44.450)

819530

N/A

65 CCW

15.44

5.5 - 6.0

1.75

819531

N/A

65 CW

(392.150)

(140 - 152)

(44.450)

N/A

819864

65 CCW

15.44

5.5 - 6.0

1.75

N/A

819865

65 CW

(392.150)

(140 - 152)

(44.450)

N/A

974996

72 CCW

15.44

5.5 - 6.0

1.75

N/A

974997

72 CW

(392.150)

(140 - 152)

(44.450)

N/A

819866

90 CCW

15.44

5.5 - 6.0

1.75

N/A

819867

90 CW

(392.150)

(140 - 152)

(44.450)

814846

N/A

56 CCW

15.75

5.0 - 5.5

1.75

814847

N/A

56 CW

(400.050)

(127 - 140)

(44.450)

813870

N/A

63 CCW

15.75

5.0 - 5.5

1.75

813871

N/A

63 CW

(400.050)

(127 - 140)

(44.450)

N/A

814934

63 CCW

15.75

5.0 - 5.5

1.75

N/A

814935

63 CW

(400.050)

(127 - 140)

(44.450)

N/A

819920

63 CCW

15.75

5.5 - 6.0

1.75

N/A

819921

63 CW

(400.050)

(140 - 152)

(44.450)

N/A

818234

79 CCW

15.88

5.5 - 6.0

1.75

N/A

818235

79 CW

(403.350)

(140 - 152)

(44.450)

819924

N/A

56 CCW

16.25

5.5 - 6.0

1.75

819925

N/A

56 CW

(412.750)

(140 - 152)

(44.450)

N/A

819840

56 CCW

16.25

5.5 - 6.0

1.75

N/A

819841

56 CW

(412.750)

(140 - 152)

(44.450)

819922

N/A

63 CCW

16.25

5.5 - 6.0

1.75

819923

N/A

63 CW

(412.750)

(140 - 152)

(44.450)

N/A

819838

63 CCW

16.25

5.5 - 6.0

1.75

N/A

819839

63 CW

(412.750)

(140 - 152)

(44.450)

816552

N/A

69 CCW

16.25

5.5 - 6.0

1.75

816553

N/A

69 CW

(412.750)

(140 - 152)

(44.450)

N/A

975662

69 CCW

16.25

5.5 - 6.0

1.75

N/A

975663

69 CW

(412.750)

(140 - 152)

(44.450)

814026

N/A

85 CCW

16.50

5.0 - 5.5

1.75

814027

N/A

85 CW

(419.150)

(127 - 140)

(44.450)

818260

N/A

56 CCW

17.31

5.0 - 5.5

1.75

818261

N/A

56 CW

(439.750)

(127 - 140)

(44.450)

Air Chamber Mounting Brackets 16.5" – Standard and Extended Service Brakes w/ Stamped Spider

(pages 37–57)

(Brackets For Cast Spider See Pages 58-80)

For Models: EB-165-5L, 6L, 7L, 8L & ES-165-5L, 6L, 7L, 8L
