58 Bendix Spicer Foundation Brakes LLC • 901 Cleveland Street • Elyria, OH 44035 • 1-866-610-9709 • www.foundationbrakes.com
Brackets with Cast Spider
Air Chamber Mounting Brackets 16.5" – Standard and Extended Service Brakes w/ Cast Spider
(pages 58–80)
(Brackets w/Stamped Spider See Pages 37-57)
For Models: EB-165-5D, 6D, 7D, 8D, 8F & ES-165-5D, 6D, 7D, 8D, 8F
L
L
CCW = Counterclockwise Rotation
CW = Clockwise Rotation
“A”
“B”
“C”
“D”
Standard
Gussetted
Bracket Angle
Barrel Length
Slack Length
Offset
Part No.
Part No.
Bracket Type
in (mm)
in (mm)
in (mm)
974684 N/A
81
CCW
5.38 5.5-6.0 1.75
974685 N/A
81
CW (136.525)
(140-152)
(44.450)
818680 N/A
90
CCW
5.38 5.5-6.0 1.75
818681
N/A
90 CW
(136.525)
(140-152)
(44.450)
810298 N/A
305
CCW
5.38 5.5
1.75
810299
N/A
305 CW
(136.525)
(140)
(44.450)
815442 N/A
305
CCW
5.38 5.5-6.0 1.75
815443
N/A
305 CW
(136.525)
(140-152)
(44.450)
815444
N/A
305 CCW
5.38
5.0
1.75
815445
N/A
305 CW
(136.525)
(127)
(44.450)
N/A 818966
300
CCW
6.38 5.5-6.0
2.81
N/A
818967
300 CW
(161.925)
(140-152)
(71.374)
1006268 N/A
15
CCW
6.38
5.0
1.75
1006269
N/A
15 CW
(162.128)
(127)
(44.450)
808994 N/A
58
CCW
6.38 5.5
1.75
808995
N/A
58 CW
(162.128)
(140)
(44.450)
817318
975460
72 CCW
6.38
5.5-6.0
1.75
817319
975461
72 CW
(162.128)
(140-152)
(44.450)
806520 N/A
75
CCW
6.38 5.5-6.0 1.75
806521
N/A
75 CW
(162.128)
(140-152)
(44.450)
806710
816882
90 CCW
6.38
5.5-6.0
1.75
806711
816883
90 CW
(162.128)
(140-152)
(44.450)
N/A 973666 120
CCW
6.38 5.5 1.75
N/A 973667 120
CW
(162.128)
(140) (44.450)
1006266 N/A
300
CCW
6.38
5.0
1.75
1006267
N/A
300 CW
(162.128)
(127)
(44.450)
1006270 N/A
300
CCW
6.38
5.5-6.0 1.75
1006271
N/A
300 CW
(162.128)
(140-152)
(44.450)
