Brake Shoe
Standard Brake Shoe and Lining Chart
Shoe & Brake
Brake Size FMSI No. Shoe Part No. Type Shoe LiningType Lining Assy Major Overhaul Kit Lining Kit
15x4 1308 1005840 EB 3030-67 (6011) 1009000 1009353 1009352
Standard 931-162 (685) 1006404 1008311 1008304
EB1504L NAB-10 808808 809812 809799
NAB-9MK 1006411 1008313 1008302
16.5 x 5 4223A 805677 High 3030-67 (6011) 806519 807177 807167
Standard 805676 Low 3030-67 (6011) 806517 807175 807167
EB1655L/D 805677 High 931-162 (685) 805714 1008503 1008523
805676 Low 931-162 (685) 805717 1008505 1008523
805677 High NAB-10 808463 809866 809865
805676 Low NAB-10 808464 809864 809865
805677 High E145A (HD2A) 806518 807176 807166
805676 Low E145A (HD2A) 806516 807174 807166
16.5 x 6 4317 805679 High 3030-67 (6011) 806533 807181 807169
Standard 805678 Low 3030-67 (6011) 806531 807179 807169
EB1656L/D 805679 High 931-162 (685) 805721 1008507 1008521
805678 Low 931-162 (685) 805725 1008510 1008521
805679 High NAB-10 808465 808630 809868
805678 Low NAB-10 808466 808631 809868
805679 High E145A (HD2A) 806532 807180 807168
805678 Low E145A (HD2A) 806530 807178 807168
805679 High E120HS 808905 809871 809870
805678 Low E120HS 808906 809869 809870
16.5 x 7 4311J 805460 High 3030-67 (6011) 807909 808632 1009354
Standard 805442 Low 3030-67 (6011) 805896 807247 1009354
EB1657L/D 805460 High 931-162 (685) 805467 807182 1009315
805442 Low 931-162 (685) 805454 1008345 1009315
805460 High NAB-10 808468 809873 809867
805442 Low NAB-10 808469 809872 809867
805442 Low E145A (HD2A) 805897 807246 1009355
805460 High E120HS 808876 809707 809703
805442 Low E120HS 808877 809705 809703
805460 High E170HS 808878 809708 809704
805442 Low E170HS 808879 809706 809704
805442 Low SMB-1A 808203 808633 1006873
1008749 High SMB-1A 1008757 1006911 1006873
16.5 x 8.63 4674 805682 Low 3030-67 (6011) 814006 814008 814007
Standard 805682 Low 931-162 (685) 805735 807184 807170
805682 Low NAB-9MK 805734 807185 807171
18 x 7 4527B 1003017 R series E120HS 810485 810516 810791
Heavy Cast E175HS 812017* 812714 N/A
EB1807R E185HS 818300 314373 314372
*Bonded and bolted shoe and lining. Lining not sold separately.
