44 Bendix Spicer Foundation Brakes LLC • 901 Cleveland Street • Elyria, OH 44035 • 1-866-610-9709 • www.foundationbrakes.com
Brackets for Stamped Spider
“A”
“B”
“C”
“D”
Standard
Gussetted
Bracket Angle
Barrel Length
Slack Length
Offset
Part No.
Part No.
Bracket Type
in (mm)
in (mm)
in (mm)
N/A 973590
127
CCW
9.31
5.5 1.75
N/A 973591
127
CW
(236.550)
(140) (44.450)
N/A 819887
308
CW
9.31
5.5 1.75
N/A 819886
308
CCW
(236.550)
(140) (44.450)
819218
N/A
315 CCW
9.31
5.5 - 6.0
1.75
819219
N/A
315 CW
(236.550)
(140 - 152)
(44.450)
N/A 813839
325
CW
9.31
5.5 1.75
N/A 813838
325
CCW
(236.550)
(140) (44.450)
N/A 974069
330
CW
9.31
5.5 1.75
N/A 974068
330
CCW
(236.550)
(140) (44.450)
N/A
974141
330 CW
9.31
5.5 - 6.0
1.75
N/A
974140
330 CCW
(236.550)
(140 - 152)
(44.450)
811612
973835
335 CCW
9.31
5.5 - 6.0
1.75
811613
973834
335 CW
(236.550)
(140 - 152)
(44.450)
N/A
815989
345 CW
9.31
5.5 - 6.0
1.75
N/A
815988
345 CCW
(236.550)
(140 - 152)
(44.450)
805902
N/A
348 CCW
9.31
5.5 - 6.0
1.75
805903
N/A
348 CW
(236.550)
(140 - 152)
(44.450)
814414
N/A
56 CCW
9.67
5.5 - 6.0
1.75
814415
N/A
56 CW
(245.650)
(140 - 152)
(44.450)
N/A
815482
56 CCW
9.67
5.5 - 6.0
1.75
N/A
815483
56 CW
(245.650)
(140 - 152)
(44.450)
814416
N/A
69 CCW
9.67
5.5 - 6.0
1.75
814417
N/A
69 CW
(245.650)
(140 - 152)
(44.450)
N/A
815484
69 CCW
9.67
5.5 - 6.0
1.75
N/A
815485
69 CW
(245.650)
(140 - 152)
(44.450)
N/A
974016
86 CCW
9.67
5.5 - 6.0
1.75
N/A
974017
86 CW
(245.650)
(140 - 152)
(44.450)
N/A
817915
346 CW
9.67
5.5 - 6.0
1.75
N/A
817914
346 CCW
(245.650)
(140 - 152)
(44.450)
N/A
819584
38 CCW
10.00
5.5 - 6.0
1.75
N/A
819585
38 CW
(254.050)
(140 - 152)
(44.450)
N/A
819586
52 CCW
10.00
5.5 - 6.0
1.75
N/A
819587
52 CW
(254.050)
(140 - 152)
(44.450)
N/A
814568
100 CCW
10.00
5.5 - 6.0
1.75
N/A
814569
100 CW
(254.050)
(140 - 152)
(44.450)
N/A
974055
346 CW
10.00
5.5 - 6.0
1.75
N/A
974054
346 CCW
(254.050)
(140 - 152)
(44.450)
806166
N/A
42 CCW
10.25
5.5 - 6.0
1.75
806167
N/A
42 CW
(260.350)
(140 - 152)
(44.450)
812852
N/A
45 CCW
10.25
5.5 - 6.0
1.75
812853
N/A
45 CW
(260.350)
(140 - 152)
(44.450)
973674 N/A
45
CCW
10.25 5.0
1.75
973675 N/A
45
CW (260.350)
(127) (44.450)
Air Chamber Mounting Brackets 16.5" – Standard and Extended Service Brakes w/ Stamped Spider
(pages 37–57)
(Brackets For Cast Spider See Pages 58-80)
For Models: EB-165-5L, 6L, 7L, 8L & ES-165-5L, 6L, 7L, 8L
