8-6 DeviceNet Adapter for use with DPI AC Drives
15 Datalink A1 Out Current value of Datalink A1 being received from the
host by this peripheral.
16 Datalink A2 Out Current value of Datalink A2 being received from the
host by this peripheral.
17 Datalink B1 Out Current value of Datalink B1 being received from the
host by this peripheral.
18 Datalink B2 Out Current value of Datalink B2 being received from the
host by this peripheral.
19 Datalink C1 Out Current value of Datalink C1 being received from the
host by this peripheral.
20 Datalink C2 Out Current value of Datalink C2 being received from the
host by this peripheral.
21 Datalink D1 Out Current value of Datalink D1 being received from the
host by this peripheral.
22 Datalink D2 Out Current value of Datalink D2 being received from the
host by this peripheral.
23 Field Flash Cntr Current value of the Field Flash Counter.
24 DPI Rx Errors Current value of the DPI CAN Transmit Error Counter
register.
25 DPI Tx Errors Maximum value of the DPI CAN Transmit Error
Counter register.
26 DNet Rx Errors Current value of the DNet CAN Receive Error Counter
register.
27 DNet Tx Errors Maximum value of the DNet CAN Receive Error
Counter register.
Table 8.4 – Diagnostic Items Accessed Using VS Utilities (Continued)
No. Name Description
