8-2 DeviceNet Adapter for use with DPI AC Drives
8.1.1 DRIVE Status Indicator
Table 8.1 – DRIVE Status Indicator: State Definitions
State Cause Corrective Action
Off The adapter is not
powered or is not
connected properly to
the drive. • Securely connect the
adapter to the drive using
the ribbon cable.
• Apply power to the drive.
Flashing
Red The adapter is not
receiving a ping
message from the
drive. • Verify that cables are
securely connected.
• Cycle power to the drive.
Solid
Red The drive has refused
an I/O connection from
the adapter.
Another DPI peripheral
is using the same DPI
port as the adapter.
Important: Cycle power to the
product after making any of the
following corrections.
• Verify that all DPI cables on
the SP600 drive are securely
connected and not
damaged. Replace cables if
necessary.
• Verify that the SP600 drive
supports Datalinks.
• Configure the adapter and
SP600 drive to use a
Datalink that is not already
being used by another
peripheral.
Orange The adapter is
connected to a product
that does not support
Reliance Electric DPI
communications. • Connect the adapter to a
product that supports
Reliance Electric DPI
communications (for
example, SP600 drives).
Flashing
Green The adapter is
establishing an I/O
connection to the
drive. • No action. This status
indicator will turn solid green
or red.
Solid
Green The adapter is properly
connected and is
communicating with
the drive. • No action.
