Troubleshooting the DeviceNet Adapter and Network 8-5
8.2 Adapter Diagnostic Items
The following diagnostic items can be accessed using VS Utilities.
Table 8.4 – Diagnostic Items Accessed Using VS Utilities
No. Name Description
1 Common Logic
Cmd Current value of the Common Logic Command being
transmitted to the host by this peripheral.
2 Prod Logic Cmd Current value of the Product Specific Logic Command
being transmitted to the host by this peripheral.
3 Reference Current value of the Product Specific Reference being
transmitted to the host by this peripheral.
4 Common Logic
Sts Current value of the Common Logic Status being
received from the host by this peripheral.
5 Prod Logic Sts Current value of the Product Specific Logic Status
being received from the host by this peripheral.
6 Feedback Current value of the Product Specific Feedback being
received from the host by this peripheral.
7 Datalink A1 In Current value of Datalink A1 In being transmitted to
the host by this peripheral (if not using Datalink A1,
this parameter should have a value of zero).
8 Datalink A2 In Current value of Datalink A2 In being transmitted to
the host by this peripheral (if not using Datalink A2,
this parameter should have a value of zero).
9 Datalink B1 In Current value of Datalink B1 In being transmitted to
the host by this peripheral (if not using Datalink B1,
this parameter should have a value of zero).
10 Datalink B2 In Current value of Datalink B2 In being transmitted to
the host by this peripheral (if not using Datalink B2,
this parameter should have a value of zero).
11 Datalink C1 In Current value of Datalink C1 In being transmitted to
the host by this peripheral (if not using Datalink C1,
this parameter should have a value of zero).
12 Datalink C2 In Current value of Datalink C2 In being transmitted to
the host by this peripheral (if not using Datalink C2,
this parameter should have a value of zero).
13 Datalink D1 In Current value of Datalink D1 In being transmitted to
the host by this peripheral (if not using Datalink D1,
this parameter should have a value of zero).
14 Datalink D2 In Current value of Datalink D2 In being transmitted to
the host by this peripheral (if not using Datalink D2,
this parameter should have a value of zero).
